Teledyne e2v Releases Emerald 2M FHD CMOS Image Sensor for Low-Cost Machine Vision

Posted Nov 01, 2018 by Teledyne e2v

Teledyne e2V has introduced a 2 Megapixel sensor in its Emerald family of CMOS image sensors. The Emerald 2M is a new CMOS image sensor designed for cost-sensitive applications that require full HD resolution images of objects in motion, without distortion. The sensor is optimized for machine vision applications and includes 5° Chief Ray Angle compensation. It is offered in a high performance CLGA package or miniaturized organic fan-out package that is only 1.19 mm thick.

As the smallest full HD global shutter sensor available, the Emerald 2M helps to lower the cost of a full HD camera system because of its compatibility with low-cost 1/3” optics. It provides flexibility to R&D engineers with its global shutter and MIPI CSI-2 interface, which allow it to utilize the latest Image Signal Processors (ISP) available for mobile applications. Digital functionalities (multi region of interest, sub-sampling, auto exposure at first frame, single frame HDR and on-chip statistics) are also embedded in the sensor to reduce processor load and hasten time-to-market.

The Emerald family of small global shutter CMOS image sensors addresses a range of machine vision applications and this 2M device has the smallest footprint. Emerald image sensors are also available in resolutions of 8, 12, 16, and 67 Megapixels.

Key features of Emerald 2M:

  • Global shutter CMOS pixel (2.8μm x 2.8μm) optimized for a maximum 5° Chief Ray Angle
  • 1/3” optical format
  • MIPI CSI-2 interface, up to 100fps
  • Package options: CLGA or fan-out organic package
  • Color Filter Array options: monochrome or color Bayer
  • On-chip functionalities: multi ROI, sub-sampling, single frame exposure, single frame HDR
