Excelitas Releases New 114mm & 118mm Lenses for Additive Manufacturing Applications

Posted Nov 08, 2019 by Excelitas Technologies

Qioptiq, an Excelitas Technologies company, has introduced two new LINOS F-Theta-Ronar lenses (114mm & 118mm) for high-power applications in additive manufacturing, energy storage and micro/macro machining. The 114mm lens offers a focal length of 114 mm at 515nm-540nm wavelength for scanning areas up to 65mm² (for green). The 118mm lens delivers a focal length of 118mm at 1030nm-1080nm for scanning areas 67mm² (for IR).

Both new fused silica F-Theta-Ronar lenses offer low absorption, short focal lengths and large entrance apertures, enabling high-precision, optimized spot quality and smaller spot sizes over the scan field for high-power or short-pulse applications. The lenses also feature a high-end coating that has been laser-damage threshold (LIDT) tested for ns at 1064nm and 532nm and fs at 1030nm and 515nm with angle correction, allowing reduced thermal focus shift and constant transmission over the scan field in high-power applications.

Additional Product Features:

  • Optimized for entrance beam diameter 10/14mm for green and 15mm for IR resulting in a minimum spot size between 8 and 17μm
  • Screw thread M85x1
  • Transmission over scan field ≥ 96 % at 515-540nm and 1030-1080nm
  • Includes interchangeable fused silica coated protective glass
  • LIDT coating: (a) 40 J/cm² at 1064 nm, 12 ns, 100 Hz and 0.9 J/cm² at 1030nm, 291 fs, 5 kHz (b) 20 J/cm² at 532 nm, 8 ns, 100 Hz and 0.6 J/cm² at 515nm, 204 fs, 50 kHz

According to Excelitas, the LINOS F-Theta-Ronar 114mm and 118mm lenses present an ideal solution for a variety of 3D printing, welding, cutting and structuring applications. Both lenses deliver the reliable operation, consistent high quality in serial production and competitive pricing that customers have come to expect from popular line of LINOS F-Theta-Ronar lenses.

Excelitas will also be showcasing the lenses at Formnext 2019 (Hall 12.0, Booth B27) from November 19 – 22, 2019 in Frankfurt, Germany.
