6-BE-Tx2-8-0266

Beam Expander by ALTECHNA
42 more products from this company
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to ALTECHNA.

The 6-BE-Tx2-8-0266 from ALTECHNA is a Beam Expander with Wavelength 266 nm, Beam Expander Diameter Housing Diameter: 45 - 50 mm, Beam Expander Length Housing Length: 130 to 145 mm. More details for 6-BE-Tx2-8-0266 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    6-BE-Tx2-8-0266
  • Manufacturer
    ALTECHNA

General Parameters

  • Beam Expander Type
    Variable Laser Beam Expanders
  • Wavelength
    266 nm
  • Magnification
    3x - 9x
  • Entrance Aperture(Input)
    11 mm
  • Substrate/Material
    UVFS
  • Transmission(%)
    0.97
  • Exit Aperture(Output)
    36 mm
  • Beam Expander Diameter
    Housing Diameter: 45 - 50 mm
  • Beam Expander Length
    Housing Length: 130 to 145 mm
  • Housing Material
    Black Anodized Aluminium
  • Housing Length
    130 to 145 mm
  • Mounting Thread
    Mounting thread: M27x1
  • Damage Threshold
    5 J/cm2 10 Hz, 10 ns, 1064 nm
  • Transmitted Wavefront Distortion
    λ/4 p-v @ 632 nm
  • Housing Diameter
    45 - 50 mm
  • Note
    Laser Line: Nd:YAG
