DCLP615 | LF101455

Beam Splitter by Delta Optical Thin Film
Request Quote

Note: Your Quotation Request will be directed to Delta Optical Thin Film.

The DCLP615 | LF101455 from Delta Optical Thin Film is a Beam Splitter with Beamsplitter Thickness 1 mm, Wavelength Range 579 to 601 nm (Reflection), 629 to 725 nm (Transmission). More details for DCLP615 | LF101455 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    DCLP615 | LF101455
  • Manufacturer
    Delta Optical Thin Film
  • Description
    579 to 725 nm Long Wave Pass beamsplitters

Physical Properties

  • Beamsplitter Dimension
    26 x 36 x 1 mm
  • Beamsplitter Thickness
    1 mm

General Parameters

  • Beamsplitter Type
    Dichroic Beamsplitters
  • Beamsplitter Shape
    Rectangular
  • Wavelength Range
    579 to 601 nm (Reflection), 629 to 725 nm (Transmission)
  • Angle of Incidence
    45 Degree
  • Note
    Reflection angle: 90 Degree
