B-GCP001

Beam Splitter by Ross Optical Industries
Request Quote

Note: Your Quotation Request will be directed to Ross Optical Industries.

The B-GCP001 from Ross Optical Industries is a Beam Splitter with Beamsplitter Diameter 25 mm(0.98 Inch), Beamsplitter Thickness 1 mm, Wavelength Range 450 to 650 nm. More details for B-GCP001 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    B-GCP001
  • Manufacturer
    Ross Optical Industries

Physical Properties

  • Beamsplitter Diameter
    25 mm(0.98 Inch)
  • Beamsplitter Thickness
    1 mm

General Parameters

  • Beamsplitter Type
    Plate Beamsplitters
  • Beamsplitter Shape
    Round
  • Wavelength Range
    450 to 650 nm
  • Reflection(%)
    30%
  • Transmission(%)
    70%
  • Split Ratio(%)
    70:30
  • Split Ratio Tolerance
    ±5%
  • Coating Material
    BBAR
  • Parallelism
    ±5 arcmin
  • Substrate/Material
    Float Glass
  • Surface Flatness
    4 Waves / 25 mm
  • Surface Quality
    80-50 scratch-dig
  • Diameter Tolerance
    ± 0.2 mm
  • Thickness Tolerance
    ± 0.2 mm
