V3 040 3000 4

Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to Gradient Lens Corporation.

The V3 040 3000 4 from Gradient Lens Corporation is a Borescope with Depth of Field(DOF) 18 mm to Infinity, Viewing Angle 0 Degrees, Field of View(FOV) 70 Degree, Probe / Insertion Tube Temperature -25 to 80 Degree C (Air), 10 to 30 Degree C (Water) (Sheath), Operating Temperature -20 to 46 Degree C (Display Unit). More details for V3 040 3000 4 can be seen below.

Product Specifications

Product Details

  • Part Number
    V3 040 3000 4
  • Manufacturer
    Gradient Lens Corporation

Connections & Interface

  • Interface
    HDMI, USB 2.0 flash memory, USB micro b for computer interface, 3.5mm headphone/mic jack

Electrical Specifications

  • AC Power supply
    100 to 240 VAC
  • Input Power Supply(AC)
    100 to 240 VAC, 50 to 60 Hz, 1.5 A Max
  • Output Power Supply(AC)
    24 V, 2.5 A

General Parameters

  • Magnification / Zoom
    5X
  • Direction of View(DOV)
    Straight Forward / Direct (0°)
  • Depth of Field(DOF)
    18 mm to Infinity
  • Viewing Angle
    0 Degrees
  • Field of View(FOV)
    70 Degree
  • Articulation Control
    4 Way
  • Articulation Angle
    ±160 Degree
  • Battery
    Lithium-Ion
  • Type
    Videoscope
  • Battery Operating Hours
    6 Hours
  • Camera
    1280 x 720 p Color CMOS sensor
  • Display
    5.5 Inch, HD
  • Fibers
    1800 Images / 30000 Images
  • Illumination
    Integrated white LED
  • Ingress Protection
    IP67 (Sheath)
  • Internal Memory
    1GB (approximately 1,800 images or 18minutes of video)
  • Li-ion Battery
    14.4 V, 92 Wh
  • Material
    Tungsten Braid (Outer), Stainless steel mono-coil with outer polymer layer (Inner)
  • Memory
    1GB (approximately 1,800 images or 18minutes of video), USB Flash drive (16GB USB flash drive included, approximately 30,000 images, 4.5 hours video)
  • Minimum Bend Radius
    32 mm
  • Photo Format
    JPEG (1280 x 720p)
  • Recording Media
    USB thumb drive
  • Sheath
    Tungsten Braid (Outer), Stainless steel mono-coil with outer polymer layer (Inner)
  • Video Format
    MPEG4 (1280 x 720p)

Environmental Conditions

  • Probe / Insertion Tube Temperature
    -25 to 80 Degree C (Air), 10 to 30 Degree C (Water) (Sheath)
  • Waterproof
    Yes
  • Operating Temperature
    -20 to 46 Degree C (Display Unit)
  • Storage Temperature
    -30 to 60 Degree C
  • Operating Humidity
    5 to 95%

Physical Properties

  • Probe / Insertion Tube Diameter
    4 mm
  • Probe / Insertion Tube Length
    3 m
  • Probe / Insertion Tube Length
    3 m
  • Insertion Cable Length
    3 m
  • Weight
    5.4 lb
