OV7251

CMOS Image Sensor by OmniVision Technologies
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to OmniVision Technologies.

The OV7251 from OmniVision Technologies is a CMOS Image Sensor with Mega Pixels 0.307 MP(VGA), Frame Rate 120 fps, Sensitivity 10.800 mW/(uW.cm-2.sec), Dynamic Range 69.6 dB, SNR 38 dB. More details for OV7251 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    OV7251
  • Manufacturer
    OmniVision Technologies
  • Description
    B&W CMOS VGA (640x480) Image Sensor with OmniPixel3-GS™ Technology

General Parameters

  • Resolution
    640(H) x 480(V)
  • Mega Pixels
    0.307 MP(VGA)
  • Optical Format
    1/7.5 Inch
  • Shutter Type
    Global Shutter
  • Frame Rate
    120 fps
  • Pixel
    0.307 MP(VGA)
  • Pixel Size
    3 µm x 3 µm
  • Active Array
    640(H)µm x 480(V)µm
  • Imaging Area
    1968 x 1488 um
  • Sensitivity
    10.800 mW/(uW.cm-2.sec)
  • Dynamic Range
    69.6 dB
  • Chroma
    B/W
  • SNR
    38 dB
  • Type
    Area Scan Sensor, Digital Sensor
  • Clock Frequency
    6 to 27 MHz
  • Supply Voltage
    1.5 to 2.8 V
  • Package Type
    CSP
  • Note
    Ray Angle: 29 Degree

Connections & Interface

  • Interface
    MIPI

Applications

  • Application
    Cellular Phones, Digital Still Cameras(DSC), Digital Video Comcorders(DVC), PC Multimedia, tablets, Wearable Devices

Physical Properties

  • Dimensions
    3910 µm x 3410 um

Temperature

  • Operating Temperature
    -30 to 70 Degree C
