IMX272AQK

CMOS Image Sensor by RESTAR FRAMOS Technologies (SONY)
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to RESTAR FRAMOS Technologies (SONY).

The IMX272AQK is a 21.27 megapixel CMOS active pixel type image sensor with a square pixel array. This sensor has a maximum 24 dB PGA circuit and 12 bits A/D converter. The 12 bits digital output makes it possible to read out the signals of 21.27 M effective pixels at high-speed of 60 frames/s in still picture mode. This product is designed for use in consumer use digital still camera only.

Product Specifications

View similar products

Product Details

  • Part Number
    IMX272AQK
  • Manufacturer
    RESTAR FRAMOS Technologies (SONY)
  • Description
    21 MP CMOS Image Sensor for Digital Cameras

General Parameters

  • Resolution
    5324 (H) x 3996 (V)
  • Mega Pixels
    21.27 MP
  • Frame Rate
    60 fps
  • Pixel
    21.27 MP
  • Pixel Size
    3.3 um (H) x 3.3 um (V)
  • Sensitivity
    1634 mV
  • Pixel Type
    Front-illuminated Sensor
  • Chroma
    Color, RGB
  • ADC Resolution
    10-bit, 12-bit
  • Clock Frequency
    72 MHz
  • Package Type
    LGA

Connections & Interface

  • Interface
    SLVS-EC

Applications

  • Application
    Digital Still Camera

Physical Properties

  • Optical Diagonal
    21.77 mm
  • Package
    194 pin LGA
