IMX283

CMOS Image Sensor by RESTAR FRAMOS Technologies (SONY)
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to RESTAR FRAMOS Technologies (SONY).

The IMX283CQJ is a diagonal 15.86 mm (Type 1) CMOS image sensor with a color square pixel array and approximately 20.30 M effective pixels. It operates with three power supply voltages: analog 2.9 V, digital 1.2 V and 1.8 V, and achieves low power consumption. The sensor realizes 12-bit digital output for shooting high-speed and high-definition moving pictures by horizontal and vertical addition and

Product Specifications

View similar products

Product Details

  • Part Number
    IMX283
  • Manufacturer
    RESTAR FRAMOS Technologies (SONY)
  • Description
    20.30 MP CMOS Image Sensor with Square Pixel for Color Cameras

General Parameters

  • Resolution
    5496 (H) x 3694 (V)
  • Mega Pixels
    20.3 MP
  • Shutter Type
    Electronic Shutter
  • Frame Rate
    21.4 to 452.03 fps
  • Pixel
    20.3 MP
  • Pixel Size
    2.40 µm (H) x 2.40 µm (V)
  • Imaging Area
    5496 (H) x 3672 (V)
  • Chroma
    Color, RGB
  • ADC Resolution
    9-bit, 10-bit, 12-bit
  • Clock Frequency
    6 to 27 MHz
  • Supply Voltage
    1.2 V (Digital), 1.8 V (Interface), 2.9 V (Analog)
  • Package Type
    LGA, Ceramic

Connections & Interface

  • Interface
    CSI-2

Applications

  • Application
    Digital Still Camera, Camcorder

Physical Properties

  • Optical Diagonal
    15.86 mm
  • Package
    118 pin LGA
  • Dimensions
    16.226 (H) x 12.654 (V) mm
