SL-EDFA-C-PA-GF

Optical Amplifier by Shanghai Sail Laser Technology
Request Quote

Note: Your Quotation Request will be directed to Shanghai Sail Laser Technology.

The SL-EDFA-C-PA-GF from Shanghai Sail Laser Technology is a Optical Amplifier with Input Power -35 to -25 dBm, Noise Figure 5 dB, Gain 25 dB, Input Power -35 to -25 dBm, Output Power 14 dBm. More details for SL-EDFA-C-PA-GF can be seen below.

Product Specifications

Product Details

  • Part Number
    SL-EDFA-C-PA-GF
  • Manufacturer
    Shanghai Sail Laser Technology
  • Description
    Gain Flattened Erbium-doped Fiber Amplifier for C-band

General Parameters

  • Amplifier Type
    Erbium-Doped Fiber Amplifier (EDFA), In-Line Amplifier
  • Connectors
    FC/APC, DB9 Female
  • Bands
    C Band
  • Gain Flatness :
    0.8 to 1.5 dB
  • Output Type
    CW
  • Package Type
    Benchtop / Rackmount, Module with Connector
  • Polarization Dependent Gain
    <0.3 dB
  • Control Mode
    Automatic Current Control (ACC)
  • Input Power
    -35 to -25 dBm
  • Noise Figure :
    5 dB
  • Gain Material
    Erbium-Doped
  • Interface
    Button or RS232
  • Package
    Benchtop / Module with connector
  • Polarization Dependancy
    Yes
  • Polarization Mode Dispersion(PMD)
    0.5 ps
  • Warranty
    1 Year
  • Gain
    25 dB
  • Input Power
    -35 to -25 dBm
  • Output Power
    14 dBm
  • Output Power :
    14 dBm
  • Supply Voltage (AC)
    100 to 240 VAC
  • Supply Voltage (DC)
    5 VDC
  • Wavelength Range
    1530 to 1565 nm

Applications

  • Application
    Fiber communication, Fiber sensing, Fiber Laser

Environmental Conditions

  • Operating Temperature
    - 5 to 55 Degree C

Fiber Parameters

  • Fiber Coupled
    Yes
  • Fiber Mode
    Single Mode
  • Fiber Type
    SMF-28e

Physical Properties

  • Dimension
    Desk: 260 x 320 x 120 mm ( W x D x H ), Module: 125 x 150 x 20 mm ( W x D x H )
