CIR-3-15-C-1-2

Fiber Optic Circulator by AFW Technologies
23 more products from this company
Request Quote

Note: Your Quotation Request will be directed to AFW Technologies.

The CIR-3-15-C-1-2 from AFW Technologies is a Fiber Optic Circulator with Insertion Loss 1 to 1.2 dB, Wavelength 1310 nm, Isolation >30 dB, Return Loss >40 dB, Optical Power 300 mW. More details for CIR-3-15-C-1-2 can be seen below.

Product Specifications

Product Details

  • Part Number
    CIR-3-15-C-1-2
  • Manufacturer
    AFW Technologies
  • Description
    3 port fiber optic circulator, 1550nm, 3mm cable jacket with package box, SMF28e singlemode fiber, 1m fiber length, FC/APC connector

General Parameters

  • Insertion Loss
    1 to 1.2 dB
  • Type
    Polarization Maintaining Optical Circulator
  • Wavelength
    1310 nm
  • No. of Ports
    3 Port
  • Isolation
    >30 dB
  • Connectors
    FC/APC
  • Return Loss
    >40 dB
  • Mode
    Single Mode
  • Tensile Load
    5 N

Environmental Conditions

  • Operating Temperature
    -5 to 70 Degree C
  • Storage Temperature
    -40 to 85 Degree C

Optical Specifications

  • Optical Power
    300 mW
  • Cross Talk
    >40 dB
  • Fiber length
    1 m
  • Fiber Type
    SMF28e
  • Polarization Dependent Loss
    <0.2 dB
  • Wavelength accuracy
    ±20 nm
Click to view more product details on manufacturer's website
