SM special Coupler

Fiber Optic Coupler by Anylink Technology
10 more products from this company
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to Anylink Technology.

The SM special Coupler from Anylink Technology is a Fiber Optic Coupler with Excess Loss 0.35 to 1 dB, Bandwidth ±15 nm, Wavelength 532 nm, 627 nm, 770 nm, 1030 nm, 2000 nm, Directivity >50 dB. More details for SM special Coupler can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    SM special Coupler
  • Manufacturer
    Anylink Technology

General Parameters

  • Configuration
    1 x 2, 2 x 2
  • Excess Loss
    0.35 to 1 dB
  • Bandwidth
    ±15 nm
  • Connectors
    LC/UPC, LC/APC, SC/UPC, SC/APC, FC/UPC, FC/APC
  • Wavelength
    532 nm, 627 nm, 770 nm, 1030 nm, 2000 nm
  • Split Ratio
    1/99 to 50/50%
  • Directivity
    >50 dB
  • Dimension
    3 x 54 mm, 3 x 70 mm, 90 x 20 x 10 mm

Applications

  • Application
    Communication System, Fiber laser and Fiber Sensor, Fiber Optic Instruments
  • Application Industry
    Fiber Optic Sensors, Optical Communication

Fiber Parameters

  • Fiber Jacket
    250 µm, 900 µm, 2 mm, 3 mm
  • Fiber Coupled
    460-HP, 630-HP, HI780C, Hi1060, SM1950
  • Fiber Modes
    Single Mode
