LTS 120-40 | 8000-6476

Laser Displacement Sensor by Vitrek
15 more products from this company
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to Vitrek.

The LTS 120-40 | 8000-6476 from Vitrek is a Laser Displacement Sensor with Measure/Sensing Distance 40 mm, Wavelength 670 nm, Resolution 0.382 µm, Supply Voltage 15 to 28 VDC, Laser Power <5 mW. More details for LTS 120-40 | 8000-6476 can be seen below.

Product Specifications

Product Details

  • Part Number
    LTS 120-40 | 8000-6476
  • Manufacturer
    Vitrek

General Parameters

  • Optical System
    Diffuse Reflection
  • Light Source
    Red Semiconductor Laser
  • Measuring Method
    Triangulation Sensors(1D)
  • Output Type
    Analog Output
  • Measure/Sensing Distance
    40 mm
  • Wavelength
    670 nm
  • Resolution
    0.382 µm
  • Supply Voltage
    15 to 28 VDC
  • Analog Voltage
    0 to 10 V
  • Beam Shape
    Spot
  • Cable Length
    2 m
  • Laser Power
    <5 mW
  • Spot Size
    100 µm
  • Laser Class
    Class 3R
  • Linearity
    12 µm
  • Output Impedance
    50 Ohms
  • RMS Noise
    6.5 µm RMS
  • Standoff
    120 mm
  • Switching Frequency
    20 kHz(response)

Connections & Interface

  • Interface
    RS-485, USB

Environmental Conditions

  • Operating Temperature
    0 to 40 Degree C
  • Storage Temperature
    -20 to 70 Degree C
