Y5-1025-45

Optical Mirror by CVI Laser Optics
Request Quote

Note: Your Quotation Request will be directed to CVI Laser Optics.

The Y5-1025-45 from CVI Laser Optics is a Optical Mirror with Wavelength Range 213 nm, Mirror Diameter 25.4 mm. More details for Y5-1025-45 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    Y5-1025-45
  • Manufacturer
    CVI Laser Optics
  • Description
    213 nm Flat Mirror with 25.4 mm Diameter

General Parameters

  • Mirror Type
    Flat Mirror, Laser Mirror
  • Mirror Shape
    Flat
  • Wavelength Range
    213 nm
  • Wavelength Region
    UV
  • Angle of Incidence
    45 Degree
  • Clear Aperture
    >85%
  • Substrate/Material
    UV Grade Fused Silica
  • Coating Material
    High Reflectivity
  • Mirror Diameter
    25.4 mm
  • Diameter Tolerance
    +0/-0.25 mm
  • Radius of Curvature
    0.1 to 5 m
  • Surface Flatness
    λ/4 (Figure)
  • Surface Quality
    20-10 scratch-dig
  • Surface Roughness
    20 Å, RMS
  • Thickness Tolerance
    ±0.25 mm
  • Application
    Beam Routing, Alignment and Sampling
