DCX-ACHR-020-080

Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to Artifex Engineering GmbH & Co. KG.

The DCX-ACHR-020-080 from Artifex Engineering GmbH & Co. KG is a Optical Lens with Focal Length 77.403 to 80 mm, Center Thickness 5.58 mm, Diameter 20 mm, Edge Thickness(ET) 4.14 mm. More details for DCX-ACHR-020-080 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    DCX-ACHR-020-080
  • Manufacturer
    Artifex Engineering GmbH & Co. KG

General Parameters

  • Lens Type
    Achromatic Lens
  • Focal Length
    77.403 to 80 mm
  • Focal Length Tolerance
    ±2%
  • Back Focal Length(BFL)
    77.403 mm
  • Effective Focal Length(EFL)
    80 mm
  • Center Thickness
    5.58 mm
  • Center Thickness Tolerance
    ±0.2mm
  • Diameter
    20 mm
  • Clear Aperture
    0.9
  • Diameter Tolerance
    +0/-0.1mm
  • Edge Thickness(ET)
    4.14 mm
  • Centration Error
    3 to 15 arcmin
  • Chamfers
    0.25 mm x 45 Degree
  • Coating
    single layer MgF2 broadband AR coating @ 550 nm
  • Substrate/Material
    BaK2, SF15
  • Surface Accuracy
    λ/4
  • Surface Quality
    60-40 scratch-dig
