SCX-25.4-50.9-UV-1064

Optical Lens by CVI Laser Optics
Request Quote

Note: Your Quotation Request will be directed to CVI Laser Optics.

The SCX-25.4-50.9-UV-1064 from CVI Laser Optics is a Optical Lens with Wavelength Range 1064 nm, Focal Length 10 mm to 10 m. More details for SCX-25.4-50.9-UV-1064 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    SCX-25.4-50.9-UV-1064
  • Manufacturer
    CVI Laser Optics
  • Description
    1064 Plano-Convex Lens with 25.4 mm Diameter

General Parameters

  • Sub Type
    Square Cylindrical Lens, Plano-Convex Cylindrical Lens
  • Lens Shape
    Cylindrical Lens, Rectangular Lens
  • Angle of Incidence
    0 Degree
  • Wavelength Range
    1064 nm
  • Focal Length
    10 mm to 10 m
  • Dimension
    25.4 x 25.4 mm
  • Center Thickness Tolerance
    ±0.25 mm
  • Clear Aperture
    >85%
  • Diameter Tolerance
    +0/-0.25 mm
  • Centration Error
    <5 arc min
  • Coating
    Anti-Reflective
  • Substrate/Material
    UV Grade Fused Silica
  • Surface Accuracy
    λ/2
  • Surface Quality
    60-40 scratch-dig
