DCX1307

Optical Lens by Foctek Photonics
Request Quote

Note: Your Quotation Request will be directed to Foctek Photonics.

The DCX1307 from Foctek Photonics is a Optical Lens with Wavelength Range 1307 nm, Focal Length 200 mm, Center Thickness 2.8 mm, Diameter 25.4 mm, Radius 206.84 mm. More details for DCX1307 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    DCX1307
  • Manufacturer
    Foctek Photonics

General Parameters

  • Sub Type
    Double-Convex Lens
  • Lens Shape
    Spherical Lens
  • Wavelength Range
    1307 nm
  • Design Wavelength
    546.1 nm
  • Focal Length
    200 mm
  • Focal Length Tolerance
    ±2%
  • Center Thickness
    2.8 mm
  • Diameter
    25.4 mm
  • Radius
    206.84 mm
  • Radius 1
    206.84 mm
  • Clear Aperture
    0.85
  • Diameter Tolerance
    +0.0-0.15 mm
  • Edge Thickness(ET)
    2 mm
  • Centration Error
    3 arcmin
  • Chamfers
    0.25 mm x 45 Degree
  • Coating
    Uncoated
  • Substrate/Material
    N-BK7
  • Surface Quality
    60-40 scratch-dig
  • Note
    Irregularity:-0.5
