DCX2201

Optical Lens by Foctek Photonics
Request Quote

Note: Your Quotation Request will be directed to Foctek Photonics.

The DCX2201 from Foctek Photonics is a Optical Lens with Wavelength Range 2201 nm, Focal Length 25 mm, Center Thickness 3.8 mm, Diameter 12.7 mm, Radius 22.38 mm. More details for DCX2201 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    DCX2201
  • Manufacturer
    Foctek Photonics

General Parameters

  • Sub Type
    Double-Convex Lens
  • Lens Shape
    Spherical Lens
  • Wavelength Range
    2201 nm
  • Design Wavelength
    546.1 nm
  • Focal Length
    25 mm
  • Focal Length Tolerance
    ±2%
  • Center Thickness
    3.8 mm
  • Diameter
    12.7 mm
  • Radius
    22.38 mm
  • Radius 1
    22.38 mm
  • Clear Aperture
    0.85
  • Diameter Tolerance
    +0.0-0.15 mm
  • Edge Thickness(ET)
    2 mm
  • Centration Error
    3 arcmin
  • Chamfers
    0.25 mm x 45 Degree
  • Coating
    Uncoated
  • Substrate/Material
    Fused Silica
  • Surface Quality
    60-40 scratch-dig
  • Note
    Irregularity:-0.5
