PCV2203

Optical Lens by Foctek Photonics
Request Quote

Note: Your Quotation Request will be directed to Foctek Photonics.

The PCV2203 from Foctek Photonics is a Optical Lens with Wavelength Range 2203 nm, Focal Length -40 mm, Center Thickness 2 mm, Diameter 12.7 mm, Radius 18.4 mm. More details for PCV2203 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    PCV2203
  • Manufacturer
    Foctek Photonics

General Parameters

  • Sub Type
    Plano-Concave Lens
  • Lens Shape
    Spherical Lens
  • Wavelength Range
    2203 nm
  • Design Wavelength
    546.1 nm
  • Focal Length
    -40 mm
  • Focal Length Tolerance
    ±2%
  • Center Thickness
    2 mm
  • Diameter
    12.7 mm
  • Radius
    18.4 mm
  • Radius 1
    18.4 mm
  • Clear Aperture
    0.85
  • Diameter Tolerance
    +0.0-0.15 mm
  • Edge Thickness(ET)
    3.1 mm
  • Centration Error
    3 arcmin
  • Chamfers
    0.25 mm x 45 Degree
  • Coating
    Uncoated
  • Substrate/Material
    Fused Silica
  • Surface Quality
    60-40 scratch-dig
  • Note
    Irregularity:-0.5
