PCX1102

Optical Lens by Foctek Photonics
Request Quote

Note: Your Quotation Request will be directed to Foctek Photonics.

The PCX1102 from Foctek Photonics is a Optical Lens with Wavelength Range 1102 nm, Focal Length 10 mm, Center Thickness 1.64 mm, Diameter 5 mm, Radius 5.17 mm. More details for PCX1102 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    PCX1102
  • Manufacturer
    Foctek Photonics

General Parameters

  • Sub Type
    Plano-Convex Lens
  • Lens Shape
    Spherical Lens
  • Wavelength Range
    1102 nm
  • Design Wavelength
    546.1 nm
  • Focal Length
    10 mm
  • Focal Length Tolerance
    ±2%
  • Center Thickness
    1.64 mm
  • Diameter
    5 mm
  • Radius
    5.17 mm
  • Radius 1
    5.17 mm
  • Clear Aperture
    0.85
  • Diameter Tolerance
    +0.0-0.15 mm
  • Edge Thickness(ET)
    1.64 mm
  • Centration Error
    3 arcmin
  • Chamfers
    0.25 mm x 45 Degree
  • Coating
    Uncoated
  • Substrate/Material
    N-BK7
  • Surface Quality
    60-40 scratch-dig
  • Note
    Irregularity:-0.5
