CAW100

Optical Lens by IMM Photonics GmbH
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to IMM Photonics GmbH.

The CAW100 from IMM Photonics GmbH is a Optical Lens with Wavelength Range 785 nm, Focal Length 9.85 mm, Diameter 5.2 mm. More details for CAW100 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    CAW100
  • Manufacturer
    IMM Photonics GmbH
  • Description
    785 nm, 9.85 mm Focal Length Precision Plastic asphere Lens with 0.195 NA

General Parameters

  • Sub Type
    Precision Aspheric Lens
  • Lens Shape
    Aspheric Lens
  • Wavelength Range
    785 nm
  • Design Wavelength
    785 nm
  • Focal Length
    9.85 mm
  • Diameter
    5.2 mm
  • Clear Aperture
    3.9 mm
  • Numerical Aperture
    0.195
  • Substrate/Material
    Plastic
  • Note
    FR: 0.15 mm, Wavefront deformation: 0.05 λ RMS

Applications

  • Application
    Laser diode modules and collimators, Sensors, Laser projection, Patient positioning, Biostimulation
