BVUV

Request Quote

Note: Your Quotation Request will be directed to Rainbow Research Optics, LLC.

The BVUV from Rainbow Research Optics, LLC is a Optical Lens with Wavelength Range 633 nm. More details for BVUV can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    BVUV
  • Manufacturer
    Rainbow Research Optics, LLC
  • Description
    10-5 scratch-dig B-Concave Lenses with UV Fused Silica Material

General Parameters

  • Sub Type
    Bi-Concave Lens
  • Lens Shape
    Spherical Lens
  • Wavelength Range
    633 nm
  • Focal Length Tolerance
    ±0.5%
  • Thickness Tolerance
    ±0.25 mm
  • Clear Aperture
    >85%
  • Diameter Tolerance
    +0.0/-0.20 mm
  • Bevel
    0.3 mm x 45 Degree
  • Centration Error
    <3 arcmin
  • Substrate/Material
    UV Grade Fused Silica
  • Surface Quality
    10-5 scratch-dig
  • Surface Irregularity(S1/S2)
    λ/10
Click to view more product details on manufacturer's website
