STSL-10.6-120-175

Optical Lens by Sintec Optronics
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to Sintec Optronics.

The STSL-10.6-120-175 from Sintec Optronics is a Optical Lens with Wavelength Range 10.6 µm, Focal Length 175 mm, Diameter 48 mm, Edge Thickness(ET) 3 mm. More details for STSL-10.6-120-175 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    STSL-10.6-120-175
  • Manufacturer
    Sintec Optronics
  • Description
    10.6 µm Zinc Selenide Scan Lenses, F-Theta Lenses

General Parameters

  • Lens Type
    Scan Lenses, F-Theta Lenses
  • Wavelength Range
    10.6 µm
  • Focal Length
    175 mm
  • Back Focal Length(BFL)
    177.4 mm
  • Effective Focal Length(EFL)
    175 mm
  • Diameter
    48 mm
  • Edge Thickness(ET)
    3 mm
  • Edge Thickness Tolerance(Te)
    +/-0.1 mm
  • Substrate/Material
    Zinc Selenide
  • Note
    Scan field: 120 x 120 mm, Flange Focal length: 178.4 mm

Applications

  • Application
    Material processing, Drilling, Welding, Cutting, Microscopy, Ophthalmology
