TS-0323Q16

Optical Lens by Sugitoh
264 more products from this company
Request Quote

Note: Your Quotation Request will be directed to Sugitoh.

The TS-0323Q16 from Sugitoh is a Optical Lens with Wavelength Range 587.6 nm, Focal Length 200 mm, Center Thickness 6.82 mm, Diameter 50 mm, Edge Thickness(ET) 3.4 mm. More details for TS-0323Q16 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    TS-0323Q16
  • Manufacturer
    Sugitoh
  • Description
    587.6 nm Synthetic Fused Silica Plano Convex Lens with 200 mm Focal Length

General Parameters

  • Sub Type
    Plano-Convex Lens
  • Lens Shape
    Spherical Lens
  • Wavelength Range
    587.6 nm
  • Design Wavelength
    587.6 nm
  • Focal Length
    200 mm
  • Focal Length Tolerance
    ±2%
  • Back Focal Length(BFL)
    195.32 mm
  • Center Thickness
    6.82 mm
  • Center Thickness Tolerance
    ±0.2 mm
  • Diameter
    50 mm
  • Diameter Tolerance
    +0/-0.1 mm
  • Edge Thickness(ET)
    3.4 mm
  • Chamfers
    0.2 mm
  • Refractive index
    1.4585/nd, 1.4681/ne
  • Substrate/Material
    SFS
  • Surface Quality
    60-40 scratch-dig
  • Note
    Decentering: 3 minutes

Applications

  • Application
    Enlarge image, Collimation, Focusing application
