SL-450-115-339Q-D30

Optical Lens by Wavelength Opto-Electronic
743 more products from this company
Request Quote

Note: Your Quotation Request will be directed to Wavelength Opto-Electronic.

The SL-450-115-339Q-D30 from Wavelength Opto-Electronic is a Optical Lens with Wavelength Range 420 to 480 nm, Focal Length 339 mm, Diameter 30 mm (Input Beam). More details for SL-450-115-339Q-D30 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    SL-450-115-339Q-D30
  • Manufacturer
    Wavelength Opto-Electronic
  • Description
    420 to 480 nm Fused Silica F-Theta Lenses

General Parameters

  • Lens Type
    F-Theta Lenses
  • Wavelength Range
    420 to 480 nm
  • Focal Length
    339 mm
  • Effective Focal Length(EFL)
    339 mm
  • Diameter
    30 mm (Input Beam)
  • Substrate/Material
    Fused Silica
  • Note
    Scan field: 140 x 140 mm, Mount thread: M55x1, Working Distance: 162.8 mm
Click to view more product details on manufacturer's website
