8100 CWDM3E

Optical Time Domain Reflectometer (OTDR) by Viavi Solutions Inc.
18 more products from this company
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to Viavi Solutions Inc..

The 8100 CWDM3E from Viavi Solutions Inc. is a Optical Time Domain Reflectometer (OTDR) with Event Dead Zone 0.8 m, Attenuation Dead Zone 4.5 m, Optical Wavelength 1431 to 1451 nm, Dynamic Range 42 dB, Pulse Width 3 ns to 20 µs. More details for 8100 CWDM3E can be seen below.

Product Specifications

Product Details

  • Part Number
    8100 CWDM3E
  • Manufacturer
    Viavi Solutions Inc.
  • Description
    1431 to 1451 nm Wavelength Range 42 dB Dynamic Range Single Mode OTDR

General Parameters

  • Event Dead Zone
    0.8 m
  • Attenuation Dead Zone
    4.5 m
  • Optical Wavelength
    1431 to 1451 nm
  • Display Resolution
    0.001 dB (Attenuation), 0.01 dB (Reflectance)
  • Distance Accuracy
    ±0.75 m ± sampling resolution ±1.10-5 x distance
  • Distance Resolution
    1 cm
  • Fiber Type
    Single Mode
  • IOR Setting
    1.30000 to 1.70000
  • Laser Safety
    Class 1
  • Linearity
    ±0.03 dB
  • Dynamic Range
    42 dB
  • Loss Threshold
    0.01 to 5.99 dB
  • Modulation
    270 Hz to 2 kHz
  • Pulse Width
    3 ns to 20 µs
  • Operation Mode
    CW
  • Distance Range
    0.5 to 320 km
  • Output Power
    0 dBm
  • Output Stability
    <±0.1 dB
  • Reflectance Accuracy
    ±2 dB
  • Sampling Point
    Upto 256000 points
  • Sampling Resolution
    4 cm
  • Wavelength accuracy
    ±3 nm

Applications

  • Application
    Test any CWDM network configuration, Qualify fiber links during CWDM installation, Wavelength provisioning, In-service troubleshooting

Physical Properties

  • Dimension
    213 x 124 x 32 mm (W x H x D)
  • Weight
    500 g
