P90-100-1064-C

Prism by CVI Laser Optics
Request Quote

Note: Your Quotation Request will be directed to CVI Laser Optics.

The P90-100-1064-C from CVI Laser Optics is a Prism with Coating Wavelength 1064 nm. More details for P90-100-1064-C can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    P90-100-1064-C
  • Manufacturer
    CVI Laser Optics
  • Description
    1064 nm N-BK7 Prisms with 25.4 mm Diameter

General Parameters

  • Prism Type
    Right Angle Prisms
  • Prism Shape
    Triangular
  • Substrate/Material
    N-BK7
  • Coating Material
    Anti-Reflective
  • Coating Wavelength
    1064 nm
  • Dimension
    25.4 x 25.4 x 25.4 mm
  • Thickness
    ±0.25 mm (Tolerance)
  • Angle of Incidence
    0 Degree
  • Angle Deviation
    <6 arcmin
  • Surface Flatness
    λ/4 (Flat Irregularity)
  • Surface Quality
    20-10 scratch-dig
  • Clear Aperture
    >85%
