GLPB2-10-31SN-2/3

Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to OptoSigma Corporation.

The GLPB2-10-31SN-2/3 from OptoSigma Corporation is a Prism with Coating Wavelength 200 to 270 nm, Prism Diameter 25.4 mm. More details for GLPB2-10-31SN-2/3 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    GLPB2-10-31SN-2/3
  • Manufacturer
    OptoSigma Corporation

General Parameters

  • Prism Type
    Glan Laser Prisms
  • Substrate/Material
    a-BBO
  • Coating Material
    Antireflection Coating MgF2 Single-Layer on Both Surface
  • Coating Wavelength
    200 to 270 nm
  • Dimension
    25.4 x 31 mm
  • Prism Diameter
    25.4 mm
  • Surface Flatness
    λ/4
  • Surface Quality
    20-10 scratch-dig
  • Beam Deviation
    3 arcsec(3")
  • Clear Aperture
    10 mm
  • RoHs
    Yes
  • Note
    Extintion ratio: 5 × 10-6, Acceptance angle: ±3.0, Transmitted wavefront distortion: λ/4, Damage Threshold: 2 J/cm2, Pulse Width: 10 ns
