AD8015

Transimpedance Amplifier by Analog Devices
6 more products from this company
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to Analog Devices.

The AD8015 from Analog Devices is a Transimpedance Amplifier with Power Supply Current 25 to 26 mA, Data Rate 0.32 Gbps, Transimpedance 8 to 24 kOhms, Power Supply Voltage 4.5 to 11 V, Bandwidth 180 to 240 MHz. More details for AD8015 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    AD8015
  • Manufacturer
    Analog Devices
  • Description
    155 Mbps Transimpedance Amplifier

Applications

  • Applications
    SONET/SDH, FDDI, Fibre Channel, Stable Operation with High Capacitance Detectors,Single-Ended to Differential Conversion

General Parameters

  • Power Supply Current
    25 to 26 mA
  • Data Rate
    0.32 Gbps
  • Transimpedance
    8 to 24 kOhms
  • Power Supply Voltage
    4.5 to 11 V
  • Bandwidth
    180 to 240 MHz
  • Package Type
    Chip, Die
  • Current Noise Density
    3 pA/√Hz
  • Input Bias Voltage
    1.6 to 2 V
  • Input Overload Current
    0.35 mApp
  • Input Referred Noise
    26.5 nArms
  • Optical Return Loss
    -10 dB
  • Optical Sensitivity
    -36 dBm
  • Output Impedance
    40 to 60 Ohms
  • Power Dissipation
    125 mW
  • Pulse Width Modulation
    500 ps
  • Rejection Ratio
    40 dB
  • Rise/Fall Time
    1.5 ns
  • Package
    Chip , DIe,8 ld SOIC

Temperature

  • Junction Temperature
    165 Degree C
  • Lead Soldering Temperature
    300 Degree C
  • Operating Temperature
    -40 to 85 Degree C
  • Storage Temperature
    -65 to 125 Degree C
