The HASO LP from Imagine Optic is a Wavefront Sensor that operates at a wavelength of 400 nm - 1100 nm (BROADBAND) & 400 nm - 800 nm (VIS). It delivers a minimum power of 0.7 nW and has an aperture size of 22 mm x 22 mm. This wavefront sensor has a repeatability below lambda/200 RMS and an absolute wavefront measurement accuracy of lambda/100 or 6 nm RMS. It has 128 x 128 microlenses and a maximum acquisition frequency of 10 Hz (10GigE). This wavefront sensor features an external trigger TTL signal input and has a beam aperture with an f-number above 5.

The HASO LP has a spatial sampling of 170 μm and local radius of curvature dynamic range from ± 0.02 m to infinity. It supports Windows 11 & 10 operating systems and can be controlled via a 10GigE interface. This wavefront sensor consumes 14 W of power and is available in a module that measures 121 mm x 104.5 mm x 100.7 mm. It is ideal for accurate laser collimation, laser optical alignment, characterization of optics, lens, protective windows & mirrors, alignment of optical systems, and laser beam testing applications.
