PP-UVFS-38.1-6.35-AR483-AR483

Optical Window by OPTOMAN
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to OPTOMAN.

The PP-UVFS-38.1-6.35-AR483-AR483 from OPTOMAN is a Optical Window with Wavelength Range 515 to 633 nm, Window Diameter 38.1 mm, Window Diameter 38.1 mm, Thickness 6.35 mm, Thickness 0.25 Inches. More details for PP-UVFS-38.1-6.35-AR483-AR483 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    PP-UVFS-38.1-6.35-AR483-AR483
  • Manufacturer
    OPTOMAN
  • Description
    515 to 633 nm 20-10 scratch-dig UVFS 38.1 mm Diameter Optical Window

General Parameters

  • Damage Threshold
    >0.1 J/cm2 @ 190 fs 1 MHz
  • Thickness Tolerance
    ±0.1 mm
  • Transmitted Wavefront Distortion
    λ/10
  • Chips
    <0.2 mm stoned
  • Window Type
    UV Window, Fused Silica Window
  • Window Shape
    Round
  • Window Color
    Ultraviolet, Visible
  • Coating
    S1/S2: AR<0.1% @ 515 nm
  • Wavelength Range
    515 to 633 nm
  • Substrate/Material
    UVFS
  • Coating Material
    AR Coating
  • Angle of Incidence
    0 Degree
  • Bevel/Chamfer
    0.2-0.3 mm x 45 Degree
  • Clear Aperture
    30 mm
  • Parallelism
    <5 arcmin
  • Surface Quality
    20-10 scratch-dig

Physical Properties

  • Window Diameter
    38.1 mm
  • Diameter Tolerance
    0/-0.1 mm
  • Window Diameter
    38.1 mm
  • Thickness
    6.35 mm
  • Thickness
    0.25 Inches
