AOM-110

Acousto-Optic Modulator by IntraAction Corp.
30 more products from this company
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to IntraAction Corp..

The AOM-110 from IntraAction Corp. is a Acousto-Optic Modulator with Modulation Bandwidth 10 / 20 MHz, Rise Time 24 to 48 ns, Optical Wavelength 442 to 633 nm, RF Power 1 to 2 W. More details for AOM-110 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    AOM-110
  • Manufacturer
    IntraAction Corp.
  • Description
    Free Space Acousto-Optic Modulator, Range from 442 to 633 nm

Fiber Parameters

  • Fiber Type
    Free Space

Physical Properties

  • Dimension
    50.8 x 16.1 x 22.4 mm

Connections & Interface

  • RF Connector
    SMA

General Parameters

  • Acousto-Optic Material
    Dense Flint Glass
  • Modulation Bandwidth
    10 / 20 MHz
  • Separation Angle
    13.4 to 19.2 mrad
  • Rise Time
    24 to 48 ns
  • Applications
    Intensity Modulation, Optical Frequency shifting
  • Beam Diameter
    0.14 to 0.28 mm
  • Optical Wavelength
    442 to 633 nm
  • Active Aperture
    0.6 mm
  • RF Power
    1 to 2 W
  • Input Impedance
    50 Ohms
  • Note
    Insertion loss: 2%
