S13434-2496

CMOS Image Sensor by Hamamatsu Photonics
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to Hamamatsu Photonics.

The S13434-2496 from Hamamatsu Photonics is a CMOS Image Sensor with Data Rate 2 MHz, Sensitivity 280 V/(lx·s), Dynamic Range 933 to 3500 times, Clock Frequency 50 kHz to 2 MHz, Supply Voltage 3.15 to 3.45 V. More details for S13434-2496 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    S13434-2496
  • Manufacturer
    Hamamatsu Photonics
  • Description
    400 to 1000 nm CMOS Image Sensor with COB Package

General Parameters

  • Resolution
    1 (H) x 2496 (V)
  • Shutter Type
    Electronic Shutter
  • Pixel Size
    5.25 x 63.5 µm
  • Imaging Area
    13.104 mm (Length)
  • Data Rate
    2 MHz
  • Sensitivity
    280 V/(lx·s)
  • Dynamic Range
    933 to 3500 times
  • Type
    Linear Image Sensor
  • Clock Frequency
    50 kHz to 2 MHz
  • Supply Voltage
    3.15 to 3.45 V
  • Package Type
    COB
  • Note
    Spectral response range: 400 to 1000 nm, Current consumption: 7 to 17 mA

Applications

  • Application
    Barcode Readers, Encoders, Various Types of Image Scanning

Physical Properties

  • Package
    Glass epoxy COB (chip on board)
  • Dimensions
    13.8 x 2.1 x 0.8 mm

Temperature

  • Operating Temperature
    -40 to 85 Degree C
  • Storage Temperature
    -40 to 85 Degree C
