IMX477

CMOS Image Sensor by RESTAR FRAMOS Technologies (SONY)
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to RESTAR FRAMOS Technologies (SONY).

The IMX477 from Sony is a 12.3 megapixel CMOS Image Sensor with a square pixel array. It uses Sony’s Stacked CMOS Image Sensor technology to achieve high-speed image capturing by column-parallel A/D converter circuits and high sensitivity and low noise image (comparing with conventional CMOS image sensor) through the backside illuminated imaging pixel structure. The sensor has an electronic shutter with variable integration time and employs R, G, and B pigment primary color mosaic filter. It operates with three power supply voltages: analog 2.8 V, digital 1.05 V and 1.8 V for input/output interface and achieves low power consumption. This product is designed for use in consumer use camcorder only.

Product Specifications

View similar products

Product Details

  • Part Number
    IMX477
  • Manufacturer
    RESTAR FRAMOS Technologies (SONY)
  • Description
    12.3 MP CMOS Image Sensor with Square Pixel Array

General Parameters

  • Resolution
    4056 (H) x 3040 (V)
  • Mega Pixels
    12.33 MP
  • Shutter Type
    Electronic Shutter
  • Frame Rate
    15 to 240 fps
  • Pixel
    12.3 MP
  • Pixel Size
    1.55 µm (H) x 1.55 µm (V)
  • Data Rate
    2.1 Gbps
  • Chroma
    Color, RGB
  • ADC Resolution
    10-bit, 12-bit
  • Clock Frequency
    6 to 27 MHz
  • Supply Voltage
    1.05 V (Digital), 1.8 V (Interface), 2.8 V (Analog)
  • Package Type
    LGA, Ceramic

Connections & Interface

  • Interface
    CSI-2

Applications

  • Application
    Camcorder

Physical Properties

  • Optical Diagonal
    7.857 mm
  • Package
    92 pin LGA
  • Dimensions
    7.564 (H) x 5.476 (V) mm
