IO-4-1480-VLP

Fiber Optic Isolator by Thorlabs Inc
129 more products from this company
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to Thorlabs Inc.

The IO-4-1480-VLP from Thorlabs Inc is a Fiber Optic Isolator with Optical Power 1.2 W, Isolation 38 dB, Wavelength 1430 to 1530 nm. More details for IO-4-1480-VLP can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    IO-4-1480-VLP
  • Manufacturer
    Thorlabs Inc
  • Description
    Free-Space Isolator, 1480 nm, Ø3.6 mm Max Beam, 1.2 W Max

General Parameters

  • Optical Power
    1.2 W
  • Type
    Free Space Isolator
  • Isolation
    38 dB
  • Wavelength
    1430 to 1530 nm
  • Beam Diameter
    3.6 mm
  • Clear Aperture
    4 mm
  • Polarizer Type
    Very Low Power (VLP)
  • Power Density
    25 W/cm2 (Blocking), 100 W/cm2 (Transmission)
  • Maximum Power
    1.2 W
  • RoHS
    Yes
  • Tuning Range
    1440 to 1520 nm

Physical Properties

  • Weight
    0.05 kg

Fiber Parameters

  • Fiber Coupled
    Free Space
