1420FIB25

Optical Filter by Knight Optical (UK) Ltd
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to Knight Optical (UK) Ltd.

The 1420FIB25 from Knight Optical (UK) Ltd is a Optical Filter with Wavelength 1413 to 1427 nm, Center Wavelength(CWL) 1420 nm, Bandwidth (FWHM) 14 nm, Blocking Wavelength 200 to 1850 nm, Filter Diameter 25 mm. More details for 1420FIB25 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    1420FIB25
  • Manufacturer
    Knight Optical (UK) Ltd

General Parameters

  • Filter Type
    Bandpass Interference Filter
  • Glass Color
    IR
  • Wavelength
    1413 to 1427 nm
  • Center Wavelength(CWL)
    1420 nm
  • Bandwidth (FWHM)
    14 nm
  • Bandwidth
    14 nm
  • Blocking Wavelength
    200 to 1850 nm
  • Optical Density
    5
  • Transmission
    40 %

Physical Properties

  • Filter Shape
    Round
  • Substrate/Material
    Silver
  • Thickness
    6.1 mm
  • Filter Diameter
    25 mm
