MID-IR COMB 3.3 um

Optical Frequency Comb by Menlo Systems

Note: Your Quotation Request will be directed to Menlo Systems.

The MID-IR COMB 3.3 um from Menlo Systems is a Optical Frequency Comb with Operating Temperature ±5 to 22 Degree C, Repetition Rate 100 MHz or 250 MHz, Average Power 120 mW, Comb Bandwidth 200 nm, Center Wavelength(CWL) 3300 nm. More details for MID-IR COMB 3.3 um can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    MID-IR COMB 3.3 um
  • Manufacturer
    Menlo Systems
  • Description
    World-leading optical frequency comb technology is now available in the midinfrared region, 3.3 um

Environmental Conditions

  • Operating Temperature
    ±5 to 22 Degree C

General Parameters

  • Repetition Rate
    100 MHz or 250 MHz
  • Average Power
    120 mW
  • Operation Mode
    Pulse
  • Comb Bandwidth
    200 nm
  • Center Wavelength(CWL)
    3300 nm
  • AC Voltage
    100 to 230 V
  • Tuning Range
    100 nm
  • Application
    Fourier-Transform Spectroscopy in the Mid-IR, Spectroscopy in the “Fingerprint Region” of Molecular Science, Chemical and Biomolecular Sensing of Molecules, Fast and Precise Detection of Atmospheric Gases
  • Note
    Frequency 50 to 60 Hz

Technical Documents

Click to view more product details on manufacturer's website
