120-10104- 0001 (ET-5000F)

Photodetector by Coherent Corp.
15 more products from this company
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to Coherent Corp..

The 120-10104- 0001 (ET-5000F) from Coherent Corp. is a Photodetector with Wavelength Range 2000 nm, Supply Voltage 3 VDC, Rise Time <28 ps, Bandwidth >10 GHz, Active Area Diameter 40 µm. More details for 120-10104- 0001 (ET-5000F) can be seen below.

Product Specifications

Product Details

  • Part Number
    120-10104- 0001 (ET-5000F)
  • Manufacturer
    Coherent Corp.
  • Description
    2000 nm Infrared Module with Connector InGaAs Photodetector

General Parameters

  • Photodetector Material
    Indium Gallium Arsenide (InGaAs)
  • Operation Mode
    Photovoltaic
  • Package Type
    Module with Connector
  • Spectral Band
    Infrared
  • Wavelength Range
    2000 nm
  • Photodetector Type
    PIN
  • Supply Voltage
    3 VDC
  • Rise Time
    <28 ps
  • Bandwidth
    >10 GHz
  • Active Area Diameter
    40 µm
  • Fall Time
    <28 ps
  • Impedance
    50 Ohms
  • Noise equivalent power(NEP)
    20 pW/vHz
  • Package
    Module with Connector
  • Rise Fall Time
    <28 ps
  • Dark Current
    <1 µA
  • Responsivity/Photosensitivity
    0.95 A/W
  • Note
    Maximum Linear Rating CW: 3 mA

Applications

  • Application
    Monitoring, High Frequency Heterodyne Applications, Time Domain and Frequency Response Measurements

Connections & Interface

  • Fiber optic connector
    FC/UPC
  • RF Connector
    SMA
