ICS APD10G0-30GSG

Note: Your Quotation Request will be directed to Integrated Compound Semiconductors (ICS).

The ICS APD10G0-30GSG from Integrated Compound Semiconductors (ICS) is a Photodiode with Wavelength Range 1260 to 1620 nm, Capacitance 120 to 140 fF, Dark Current 15 to 30 nA, Responsivity/Photosensitivity 8 to 10 A/W, Active Area Diameter 29 to 31 µm. More details for ICS APD10G0-30GSG can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    ICS APD10G0-30GSG
  • Manufacturer
    Integrated Compound Semiconductors (ICS)
  • Description
    InGaAs, InAIAs, Avalanche Photodiode from 1260 to 1620 nm

General Parameters

  • Breakdown Voltage
    26 to 35 V
  • Cut-Off Frequency
    6.2 to 6.5 GHz
  • Forward Voltage
    1.1 to 1.2 V
  • Module
    No
  • Package
    Chip
  • Package Type
    Chip
  • Photodetector Type
    Avalanche
  • Operation Mode
    Photoconductive
  • Wavelength Range
    1260 to 1620 nm
  • Photodiode Material
    InGaAs, InAIAs
  • Capacitance
    120 to 140 fF
  • Dark Current
    15 to 30 nA
  • Responsivity/Photosensitivity
    8 to 10 A/W

Physical Properties

  • Active Area Diameter
    29 to 31 µm

Temperature

  • Operating Temperature
    -40 to 85 Degree C
