ICS PIN25G2-20GSG

Note: Your Quotation Request will be directed to Integrated Compound Semiconductors (ICS).

The ICS PIN25G2-20GSG from Integrated Compound Semiconductors (ICS) is a Photodiode with Wavelength Range 1260 to 1620 nm, Capacitance 105 to 130 ff, Dark Current 1.5 to 3 nA, Responsivity/Photosensitivity 0.52 to 0.7 A/W, Active Area Diameter 19 to 21 µm. More details for ICS PIN25G2-20GSG can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    ICS PIN25G2-20GSG
  • Manufacturer
    Integrated Compound Semiconductors (ICS)
  • Description
    InGaAs, PIN Photodiode from 1260 to 1620 nm

General Parameters

  • Breakdown Voltage
    -30 to -26 V
  • Cut-Off Frequency
    18 GHz
  • Forward Voltage
    0.6 to 0.8 V
  • Module
    No
  • Package
    Chip
  • Package Type
    Chip
  • Photodetector Type
    PIN
  • Operation Mode
    Photoconductive
  • Wavelength Range
    1260 to 1620 nm
  • Photodiode Material
    InGaAs
  • Capacitance
    105 to 130 ff
  • Dark Current
    1.5 to 3 nA
  • Responsivity/Photosensitivity
    0.52 to 0.7 A/W

Physical Properties

  • Active Area Diameter
    19 to 21 µm

Temperature

  • Operating Temperature
    -40 to 85 Degree C
