HE-5300-S-I Series

Scientific & Industrial Camera by Emergent Vision Technologies, Inc.
127 more products from this company
Request Quote

Note: Your Quotation Request will be directed to Emergent Vision Technologies, Inc..

The HE-5300-S-I Series from Emergent Vision Technologies, Inc. is a Scientific & Industrial Camera with Mega Pixels 5.24 MP, Frame Rate 130 fps, Bit Depth 8 Bit, 12 Bit. More details for HE-5300-S-I Series can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    HE-5300-S-I Series
  • Manufacturer
    Emergent Vision Technologies, Inc.
  • Description
    5 GigE Area-Scan Cameras HE Series with 5.24 Mega Pixel

Applications

  • Application
    Food and Beverage Inspection, Agricultural Imaging, Semiconductor and Electronics Inspection, Recycling / Material Sorting, Medical Imaging
  • Application Industry
    Food & Beverage, Medical and Healthcare, Industrial Inspection and Automation, Scientific and Research

Connections & Interface

  • Data Interface
    1, 2.5, 5GigE, GenICam

General Parameters

  • Camera Type
    Area Scan Cameras
  • Mega Pixels
    5.24 MP
  • Resolution
    2560(H) x 2048(V)
  • Sensor Type
    CMOS
  • Shutter Type
    Global Shutter
  • Frame Rate
    130 fps
  • Pixel Size(H x V)
    3.45 x 3.45 µm
  • Exposure Time :
    5 µs to 1 s
  • Sensor Format
    1/1.4 Inches
  • Dynamic Range
    86 dB
  • Bit Depth
    8 Bit, 12 Bit
  • Sensor Configurations
    Monochrome
  • Detection Wavelength Range
    Short-Wave IR
  • Trigger Mode
    Software, External (Pulse or Edge)
  • Warranty
    2 Years
  • Compliances
    CE, FCC, RoHS, WEEE
  • Compatible System
    Win10 (64 bit), Linux (64 bit)
  • Chrome
    Monochrome
  • Integration Time
    5 µs to 1 s
  • Lens Mount
    C-Mount
  • Voltage(DC)
    12 V
  • Power Consumption
    9 W
  • Optical Diagonal
    11.4 mm
  • RoHs
    Yes
  • Sensor Manufacturer
    Sony
  • Sensor Model Number
    IMX992

Physical Properties

  • Dimension
    29 x 29 x 29 mm
  • Weight
    80 g

Temperature

  • Operating Temperature
    0 to 45 Degree C
  • Storage Temperature
    -30 to 60 Degree C
