MT80-A0,4-2000

Acousto-Optic Modulator by AA Opto Electronic
Download Datasheet Request Quote

Note: Your Quotation Request will be directed to AA Opto Electronic.

The MT80-A0,4-2000 from AA Opto Electronic is a Acousto-Optic Modulator with Operating Temperature 10 to 40 Degree C, Storage Temperature -20 to 50 Degree C, Modulation Bandwidth 15 MHz, Rise Time 32 to 48 ns, Optical Wavelength 1900 to 2100 nm. More details for MT80-A0,4-2000 can be seen below.

Product Specifications

Product Details

  • Part Number
    MT80-A0,4-2000
  • Manufacturer
    AA Opto Electronic
  • Description
    Free Space AO Modulator/Shifter from 1900 to 2100 nm

Fiber Parameters

  • Fiber Type
    Free Space

Temperature

  • Operating Temperature
    10 to 40 Degree C
  • Storage Temperature
    -20 to 50 Degree C

Physical Properties

  • Dimension
    50.9 x 22.4 x 17.3 mm
  • Weight
    50 g

General Parameters

  • Acousto-Optic Material
    Tellurium Dioxide (TeO2)
  • Modulation Bandwidth
    15 MHz
  • Separation Angle
    37 to 38 mrad
  • Rise Time
    32 to 48 ns
  • Applications
    Intensity modulation, Frequency Shifter
  • Beam Diameter
    0.2 to 0.3 mm
  • Optical Wavelength
    1900 to 2100 nm
  • Acoustic Velocity
    4.2 mm / µsec
  • Active Aperture
    0.4 x 1 mm2
  • RF Power
    2.2 to 2.5 W
  • Extinction Ratio
    30 dB
  • Fall Time
    32 to 48 ns
  • Frequency Shift
    ±80 MHz
  • Input Impedance
    50 Ohms
  • Polarization
    Linear
  • Power Density
    10 W/mm²
  • RoHS
    Yes
  • Transmission
    95 to 98%
  • VSWR
    1.20:1
