C-60+

Laser by AMTEC
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to AMTEC.

The C-60+ from AMTEC is a Laser with Wavelength 10.55 to 10.63 µm, Power 60 W, Operating Temperature 5 to 45 Degree C. More details for C-60+ can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    C-60+
  • Manufacturer
    AMTEC
  • Description
    10.55 to 10.63 nm CO2 Laser system with 60 W Power

General Parameters

  • Type
    Laser System
  • Configuration
    Laser Head with Control Unit (Integrated)
  • Application Industry
    Automotive / Industrial & Manufacturing
  • Application
    Marking, Etching, Cutting, Drilling – non-metallic materials, Engraving, Wire stripping, Drilling – printed circuit boards, Paint removal/cleaning, Micro-machining-non-metals materials
  • Operation Mode
    CW Laser
  • Wavelength
    10.55 to 10.63 µm
  • Power
    60 W
  • Technology
    Gas Laser
  • Tunable
    No
  • Fiber Coupled
    No
  • Laser Color
    Infrared
  • Polarization Orientation
    Linear
  • Polarization ratio :
    >100:1
  • Beam Divergence :
    7.5 mrad
  • Gain Medium Type
    Gas Laser
  • Duty Cycle :
    0 to 100%
  • Laser Cavity Material
    CO2
  • Laser Gain Medium
    Molecular Lasers
  • Current
    20 A
  • Modulation Frequency
    0 to 200 kHz
  • Power Stability
    ±4%
  • Voltage
    48 VDC
  • Note
    Heat Dissipation: <1200 W

Physical Properties

  • Dimension
    667 x 93 x 155 mm
  • Weight
    10 kg

Environmental Conditions

  • Cooling Method
    Air Cooled
  • Operating Temperature
    5 to 45 Degree C

Technical Documents
Click to view more product details on manufacturer's website
