GL 532-40

Laser by AMTEC
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to AMTEC.

The GL 532-40 from AMTEC is a Laser with Wavelength 532 nm, Power >40 W, Pulse Width <25 ns, Repetition Rate 0 to 500 kHz, Operating Temperature 18 to 35 Degree C. More details for GL 532-40 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    GL 532-40
  • Manufacturer
    AMTEC
  • Description
    532 nm Green Fiber Coupled Laser system with >40 W Power

General Parameters

  • Type
    Laser System
  • Configuration
    Laser Head with Control Unit (Integrated)
  • Ultrafast Laser
    Nanosecond Lasers
  • Application Industry
    Automotive / Industrial & Manufacturing, Scientific Research
  • Application
    Marking, Material processing, Micro-machining, Scribing, Si Ablation, Solar / Photovoltaics, Texturing
  • Operation Mode
    Pulsed Laser
  • Wavelength
    532 nm
  • Power
    >40 W
  • Pulse Width
    <25 ns
  • Repetition Rate
    0 to 500 kHz
  • Pulse to Pulse Stability
    <2 to 5% RMS
  • Tunable
    No
  • Fiber Coupled
    Yes
  • Laser Color
    Green
  • Polarization
    Vertical
  • Polarization ratio :
    100:1
  • Transverse Mode
    TEM00
  • Beam Divergence :
    <0.9 mrad
  • Beam Shape
    Circular
  • Power Consumption
    <400 W
  • Pointing Stability :
    <±25 µrad/Degree C
  • Power Supply
    110 to 220 VAC, 50 to 60 Hz

Physical Properties

  • Dimension
    635 x 153 x 115 mm (L x W x H)
  • Weight
    12.7 kg
  • Beam Diameter
    1 mm

Environmental Conditions

  • Cooling Method
    Water Cooled
  • Relative Humidity
    8 to 95%
  • Operating Temperature
    18 to 35 Degree C
  • Storage Temperature
    -20 to 50 Degree C

Technical Documents
Click to view more product details on manufacturer's website
Request a Quote
