940nm-ICLLM

Laser by Berlin Lasers
232 more products from this company
Request Quote

Note: Your Quotation Request will be directed to Berlin Lasers.

The 940nm-ICLLM from Berlin Lasers is a Laser with Wavelength 940 nm, Power 100 mW, 200 mW, 300 mW, 400 mW, 500 mW, Operating Temperature 10 to 45 Degree C, Storage Temperature -10 to 50 Degree C. More details for 940nm-ICLLM can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    940nm-ICLLM
  • Manufacturer
    Berlin Lasers
  • Description
    940 nm Infrared Cross Line Laser Modules with 100 to 500 mW Power

General Parameters

  • Type
    Laser Module
  • Configuration
    OEM Laser Module
  • Application Industry
    Defense / Military & Aerospace, Entertainment, Automotive / Industrial & Manufacturing, Medical, Scientific Research
  • Application
    Industrial Cross Line Lasers get wide Applications in Machinery Processing, Crosshair Template Positioning, Industrial Equipment, Laser Medical Devices of CT/CB/NMR Cross Lesions, Laser Locators, and Car Wheel Alignment etc
  • Operation Mode
    CW Laser, Pulsed Laser
  • Wavelength
    940 nm
  • Power
    100 mW, 200 mW, 300 mW, 400 mW, 500 mW
  • Tunable
    No
  • Fiber Coupled
    No
  • Laser Color
    Infrared
  • Transverse Mode
    TE
  • Beam Divergence :
    6 mrad
  • Current
    <1000 mA
  • Voltage
    5 VDC, 9 VDC
  • Warranty
    6 Months
  • Note
    Lifetime: >8000 hours

Physical Properties

  • Dimension
    16 x 71 mm (D x L), 26 x 150 mm (D x L)
  • Beam Diameter
    <2.5 mm

Environmental Conditions

  • Operating Temperature
    10 to 45 Degree C
  • Storage Temperature
    -10 to 50 Degree C
