YUCCA 45-343

Laser by BLOOM LASERS
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to BLOOM LASERS.

YUCCA, the UV fiber laser, provides high power at high pulse repetition rates with short nanosecond pulses. It is fully designed to improve laser process quality with shorter pulse widths and increase productivity with higher pulse repetition rates. Its innovative patented fiber design enables a unique combination of short nanosecond pulses, performance for high-speed process and reduced overall processing cost. With a constant short nanosecond pulse duration and beam quality over the whole pulse repetition rate range, YUCCA is the right laser source for the next generation of UV laser micromachining equipment targeting higher throughput.YUCCA is designed with high-end methodologies to exceed industrial quality standards and to guarantee reliability and serviceability. Manufactured with field proven technology and qualified components, good practices and high-quality, YUCCA is the right answer for 24/7 operations in extended production cycle environments.

Product Specifications

View similar products

Product Details

  • Part Number
    YUCCA 45-343
  • Manufacturer
    BLOOM LASERS
  • Description
    High power short nanosecond UV laser for high-speed precision micromachining

General Parameters

  • Type
    Laser System
  • Configuration
    Laser Head with Control Unit (Separate)
  • Ultrafast Laser
    Nanosecond Lasers
  • Application Industry
    Automotive / Industrial & Manufacturing
  • Application
    Cutting, Drilling, Etching, Selective Soldering, Surface Treatment, 3D Printing, Laser Printers
  • Operation Mode
    Pulsed Laser
  • Wavelength
    343 nm
  • Wavelength Accuracy
    ±0.1 nm
  • Power
    20 to 45 W
  • Pulse Width
    2 to 10 ns
  • Repetition Rate
    Single-shot to 1000 kHz
  • Pulse to Pulse Stability
    <3% rms
  • Tunable
    No
  • Fiber Coupled
    Yes
  • Laser Color
    Ultraviolet
  • Polarization
    Vertical
  • Polarization Orientation
    Linear
  • Polarization ratio :
    >100:1
  • Transverse Mode
    TEM00
  • Beam Divergence :
    <0.3 mrad
  • Beam Quality Factor (M2) :
    <1.2
  • Warm up time
    <30 min (Cold Start), <10 min (Warm Start)
  • Power Consumption
    <900 W
  • Power Stability
    <2%
  • Peak Power
    up to 40 kW
  • Pointing Stability :
    <25 µrad
  • Interface
    USB, RS-232, Ethernet
  • Power Supply
    100 to 240 VAC, 50 to 60 Hz
  • Note
    Waist Location: ±6 m, Astigmatism: <30%, Minimum Cooling Power: 700 W

Physical Properties

  • Package
    Benchtop / Rackmount
  • Laser Head Dimension
    1146 x 250 x 169 mm (L x W x H)
  • Laser Head Weight
    50 kg
  • Power Supply Dimension
    506 x 483 x 177 mm (L x W x H)
  • Power Supply Weight
    25 kg
  • Beam Diameter
    3.5 mm

Environmental Conditions

  • Relative Humidity
    10 to 95%
  • Altitude
    Sea level to 11000 meter
  • Operating Temperature
    15 to 35 Degree C
  • Storage Temperature
    0 to 50 Degree C
