PGL-H-655

Laser by CNI Laser
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to CNI Laser.

The PGL-H-655 from CNI Laser is a Laser with Wavelength 655 nm, Power 0.001 to 1 W, Output Power (CW) 0.001 to 1 W, Operating Temperature 10 to 35 Degree C. More details for PGL-H-655 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    PGL-H-655
  • Manufacturer
    CNI Laser

General Parameters

  • Type
    Laser Module
  • Configuration
    Laser Head with Control Unit (Integrated)
  • Ultrafast Laser
    Nanosecond Lasers
  • Application Industry
    Scientific / Research, Entertainment
  • Application
    Test & Measurement, Spectrum Analysis, Laser Light Shows
  • Operation Mode
    CW laser
  • Wavelength
    655 nm
  • Wavelength Accuracy
    ±10 nm
  • Power
    0.001 to 1 W
  • Output Power (CW)
    0.001 to 1 W
  • Tunable
    No
  • Fiber Coupled
    No
  • Laser Color
    Red
  • Transverse Mode
    TE00
  • Beam Divergence :
    2.5 to 4 mrad
  • Warm up time
    5 Minutes
  • Voltage
    DC to 3 V
  • RoHS
    Yes
  • Warranty
    6 Month
  • Note
    Expected Lifetime: 5000 Hours

Physical Properties

  • Power Supply Dimension
    20 x 62 (L) mm
  • Weight
    0.3 Kg
  • Beam Diameter
    5 × 8 mm

Environmental Conditions

  • Operating Temperature
    10 to 35 Degree C
