LDP-100MQU

Laser by Coherent Corp.
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to Coherent Corp..

The LDP-100MQU from Coherent Corp. is a Laser with Wavelength 355 nm, Power 5 to 12 W, Output Power (Pulsed) 5 to 12 W, Pulse Energy 0.3 to 1.6 mJ, Pulse Width 105 to 400 ns. More details for LDP-100MQU can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    LDP-100MQU
  • Manufacturer
    Coherent Corp.
  • Description
    UV DIODE-PUMPED Nd:YAG LASER

General Parameters

  • Type
    Laser System
  • Configuration
    Laser Head with Control Unit (Integrated)
  • Ultrafast Laser
    Nanosecond Lasers
  • Application Industry
    Automotive / Industrial & Manufacturing
  • Application
    Welding, Cutting, Drilling, Marking, Engraving, Cleaning, Trimming
  • Operation Mode
    Pulsed Laser
  • Wavelength
    355 nm
  • Power
    5 to 12 W
  • Output Power (Pulsed)
    5 to 12 W
  • Pulse Energy :
    0.3 to 1.6 mJ
  • Pulse Energy
    0.3 to 1.6 mJ
  • Pulse Width
    105 to 400 ns
  • Technology
    DPSS Laser, Q-Switched Laser, Solid State Laser
  • Tunable
    No
  • Fiber Coupled
    No
  • Mode
    Multi-Mode
  • Laser Color
    Ultraviolet
  • Polarization Orientation
    Linear
  • Beam Divergence :
    2.5 mrad
  • Gain Medium Type
    Solid State Laser
  • Laser Cavity Material
    Nd:YAG
  • Laser Gain Medium
    Neodymium-Doped Lasers
  • Laser Class
    Class IV
  • Modulation Frequency
    50 to 60 Hz
  • Power Consumption
    2 kW
  • Peak Power
    0.42 to 15.2 kW
  • Power Supply
    220 +10% VAC, 1-phase, 50/60 Hz, 20A

Physical Properties

  • Beam Diameter
    1 mm

Environmental Conditions

  • Cooling Method
    Water-Cooled
  • Operating Temperature
    18 to 30°C
