LDP-200MQU-HP-Dual

Laser by Coherent Corp.
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to Coherent Corp..

The LDP-200MQU-HP-Dual from Coherent Corp. is a Laser with Wavelength 355 nm, Power 90 to 100 W, Output Power (Pulsed) 90 to 100 W, Pulse Energy 1.8 to 12 mJ, Pulse Width 110 to 180 ns. More details for LDP-200MQU-HP-Dual can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    LDP-200MQU-HP-Dual
  • Manufacturer
    Coherent Corp.
  • Description
    UV DIODE-PUMPED Nd:YAG LASER

General Parameters

  • Type
    Laser System
  • Configuration
    Laser Head with Control Unit (Integrated)
  • Ultrafast Laser
    Nanosecond Lasers
  • Application Industry
    Automotive / Industrial & Manufacturing
  • Application
    Welding, Cutting, Drilling, Marking, Engraving, Cleaning, Trimming
  • Operation Mode
    Pulsed Laser
  • Wavelength
    355 nm
  • Power
    90 to 100 W
  • Output Power (Pulsed)
    90 to 100 W
  • Pulse Energy :
    1.8 to 12 mJ
  • Pulse Energy
    1.8 to 12 mJ
  • Pulse Width
    110 to 180 ns
  • Technology
    DPSS Laser, Q-Switched Laser, Solid State Laser
  • Tunable
    No
  • Fiber Coupled
    No
  • Mode
    Multi-Mode
  • Laser Color
    Ultraviolet
  • Polarization Orientation
    Linear
  • Beam Divergence :
    4 mrad
  • Gain Medium Type
    Solid State Laser
  • Laser Cavity Material
    Nd:YAG
  • Laser Gain Medium
    Neodymium-Doped Lasers
  • Laser Class
    Class IV
  • Modulation Frequency
    50 to 60 Hz
  • Power Consumption
    2.3 kW
  • Peak Power
    10 to 109 kW
  • Power Supply
    220 +10% VAC, 1-phase, 50/60 Hz, 30A

Physical Properties

  • Beam Diameter
    2 mm

Environmental Conditions

  • Cooling Method
    Water-Cooled
  • Relative Humidity
    10 to 90% (Non-Condensing)
  • Operating Temperature
    18 to 30°C
  • Storage Temperature
    5 to 60°C
