FPYL-261-XXXXT

Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to Frankfurt Laser Company.

The FPYL-261-XXXXT from Frankfurt Laser Company is a Laser with Wavelength 261 nm, Power 200 to 1000 mW, Operating Temperature 10 to 35 Degree C. More details for FPYL-261-XXXXT can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    FPYL-261-XXXXT
  • Manufacturer
    Frankfurt Laser Company
  • Description
    1 mW Power Diode Pumped Solid-State Lasers with 261 nm

General Parameters

  • Type
    Laser System
  • Configuration
    Laser Head with Control Unit (Integrated)
  • Application Industry
    Automotive / Industrial & Manufacturing, Scientific Research
  • Application
    Semiconductor Inspection, Flow Cytometry, Spectroscopy
  • Operation Mode
    CW Laser
  • Wavelength
    261 nm
  • Wavelength Accuracy
    ±1 nm
  • Power
    200 to 1000 mW
  • Technology
    DPSS Laser
  • Tunable
    No
  • Fiber Coupled
    No
  • Laser Color
    Ultraviolet
  • Polarization
    Vertical, Horizontal
  • Polarization ratio :
    >50:1
  • Transverse Mode
    TEM00
  • Beam Divergence :
    <3 mrad
  • Gain Medium Type
    Solid State Laser
  • Warm up time
    <10 minutes
  • Power Stability
    <1%, <2%, <3%
  • Voltage
    12 VDC
  • Note
    Expected Lifetime: 10000 hours, Chiller dimension: 345 x 248 x 215 mm (L x W x H), Chiller weight: 10.5 kg

Physical Properties

  • Package
    Benchtop
  • Laser Head Dimension
    370 x 236 x 202 mm (L x W x H)
  • Beam Diameter
    3 mm

Environmental Conditions

  • Cooling Method
    Water Cooled
  • Operating Temperature
    10 to 35 Degree C
